Precision parts
The MCT130XY series has excellent planar performance and geometric characteristics due to its integrated dual-axis design. Driven by a linear motor, equipped with a rigid, creep-resistant cross-roller guide, high-resolution position feedback, is the smoothest and most accurate movement.
Learn more
The MCHL series is driven by a linear motor and is equipped with high-precision, high-rigidity, creep-resistant cross-roller guides. MCHL is optimized for high dynamics and stiffness to achieve high servo bandwidth while maximizing the available aperture and keeping the overall height to a minimum.
Learn more
The APRL series uses porous material as the air support, has a large size air bearing surface, can produce high stiffness and large load capacity, not only has excellent axial and radial error motion, but also has excellent tilt error motion. The design of the APRL series direct drive rotating platform has been optimized to minimize the height of the platform and reduce the error associated with "stacking.
Learn more
The APL210Z series is driven by a linear motor without backlash, in which the porous medium produces a uniform air film to realize the smooth movement of the motion table without friction and vibration. Due to the non-contact structure and the system is equipped with a high-precision grating ruler, the following error of the system has been improved compared with the mechanical guide structure, and the positioning accuracy and repeated positioning accuracy have been significantly improved.
Learn more
The APL210 series is driven by a linear motor without backlash, in which the porous medium produces a uniform gas film to realize the smooth movement of the motion table without friction and vibration. Due to the non-contact structure and the system is equipped with a high-precision grating ruler, the following error of the system has been improved compared with the mechanical guide structure, and the positioning accuracy and repeated positioning accuracy have been significantly improved.
Learn more
HPL410 series by no backlash linear motor drive, the use of liquid static pressure technology to achieve precision movement of the guide rail, with high damping, high rigidity, and can achieve high and low speed transverse movement characteristics, it is the best solution to achieve rapid reciprocating oscillation motion, low speed no friction, no stick-slip phenomenon, which can achieve ultra high positioning accuracy.
Learn more
The APRH series uses porous materials as air support, which can achieve high stiffness and large load capacity. It not only has excellent axial and radial errors, but also has excellent tilt error motion. The resulting performance is significantly better than other rotating air bearing tables and spindles, greatly facilitating applications that require superior planar performance.
Learn more
The MARH series turntable is driven by a frameless motor. Since the motor is non-contact, there is no need to maintain brushes or gears. The turntable is supported by NSK angular contact ball bearings and is equipped with incremental optical encoders, which enables the MARH series turntable to achieve stable and high-performance operation at a low cost.
Learn more
The ARS80 series uses small orifice throttling as the air support, and has a large air bearing surface, which can produce high stiffness and large load capacity, with extremely low radial runout and axial runout. The ARS80 series is precisely calculated and has excellent static and dynamic accuracy.
Learn more
The APOS series is driven by a non-backlash linear motor, in which the porous medium produces a uniform air film to realize the smooth movement of the motion table without friction and vibration. Due to the open air floating structure, it is more compact than the ordinary air floating structure. The system is equipped with a high-precision grating ruler, which improves the texture of the system's follow-up error compared to the mechanical guide structure, and the positioning accuracy and repeated positioning accuracy have been significantly improved.
Learn more
We sincerely look forward to working with you!
